Features:
Easy and fast installation
High performance piston pump and easy-to-use control panel
Icon style control panel, easy to maintain and operate
The electrical control box has high sealing performance and a protection level of IP54
The connector pins are treated with gold plating to ensure stable transmission
Large basket filter, no need for daily cleaning, no need to bring carbides into the system during replacement
The melting cylinder adopts progressive fin heating, combined with DuPont Teflon spraying, to reduce carbonization phenomenon
Technical scope:
Number of pumps: One high-performance piston pump
Maximum working pressure: 85Bar/8.5MPa (1230Psi)
Working temperature range: 40-230 ℃ (110-450F)
Temperature control accuracy: ± 1 ℃ (2F)
Environmental temperature range: 0-60 ℃ (32-140 ℃)
Sensor type: Ni120
Up to 4 throat outputs
Melting speed: 9 kg/hour
