Features:
Can optimize the arrangement of glue
The position of the stable rubber band line
Improve the ability to resist creep
Reduce the consumption of glue
Technical scope:
Compatibility of modules and nozzles
Nozzle aperture: 0.51 mm (0.020 inches)
Distance from nozzle to substrate: contact
Glue flow rate: 2.5 to 25 grams per minute per dispensing hole
Maximum weight: 25-100 milligrams per meter
Production speed: 100-400 meters per minute (330-1968 feet)
Adhesive viscosity range: 8000-15000 cps (recommended 10000 cps)
Working temperature: 70 ℃ -205 ℃ (160 ℃ -400F)
Air consumption: 0.07 to 0.21 standard cubic inches per share per minute
Air pressure (typical): 0.3-1 bar (5-15 kilograms per square centimeter)
Working adhesive pressure: 13.8-55.2 bar (200-800 kilograms per square centimeter)
Maximum hydraulic pressure: 89.6 bar (1300 kilograms per square centimeter)
