Features:
Precision control competition
The fiber size, density, and pattern width of the adhesive can be controlled,
To achieve better bonding performance
Reduce thermal deformation on thin materials
Perfect adhesive breaking effect
Technical scope:
compatibility
Glue edge control ± 2mm (± 0.08in)
Nozzle hole size: 0.46mm (0.018in)
Distance from nozzle to substrate: 10-30mm (0.38-1.2in), 20mm (recommended)
Maximum weight: 100 grams per minute per nozzle at 10000 cpo
Production speed: 10-400 meters (33-1312 feet/minute)
Rubber fiber size: 50-100 microns
Adhesive viscosity: 1500-10000 cps (70-205 ℃)
Glue flow rate: 2.5-25 grams per minute per hole
Air consumption: 0.5-1.0 standard cubic feet per minute per hole
Air pressure (typical): 0.2-1 bar (3-15 kilograms per square centimeter)
Working adhesive pressure: 13.8-55.2 bar (200-800 kilograms per square centimeter)
Maximum glue output: 14GSM@300 Meters per minute 10GSM@100 Meters per minute
